J | Pitch circle diameter | 133.35 | mm |
D | Outside diameter | 160 | mm |
H/T | Hole/Thread | 4x13.5 | mm |
d | Bore diameter | 31 | mm |
C | D-shape hole cut out dimension | 34.9 | mm |
G | Internal Thread | 3/4”-16UNF | mm |
L | Total length | 78 | mm |
L1 | Total flange length | 63 | mm |
F | Length of threaded part | 40 | mm |
kg | Mass | 4.1 | kg |
Cdyn | Dynamic load rating | 66.35 | kN |
Co | Static load rating | 56.5 | kN |
Pu | Fatigue load limit | 2.37 | kN |
J | Pitch circle diameter | 133.35 | mm |
D | Outside diameter | 160 | mm |
H/T | Hole/Thread | 4x13.5 | mm |
d | Bore diameter | 31 | mm |
C | D-shape hole cut out dimension | 34.9 | mm |
G | Internal Thread | 3/4”-16UNF | mm |
L | Total length | 78 | mm |
L1 | Total flange length | 63 | mm |
F | Length of threaded part | 40 | mm |
kg | Mass | 4.1 | kg |
Cdyn | Dynamic load rating | 66.35 | kN |
Co | Static load rating | 56.5 | kN |
Pu | Fatigue load limit | 2.37 | kN |
