UC300 H-F

Availability:
Quantity:
Inquire Add to Basket

PDF Export



Shaft diameter

mm/in.

Bearing Type

NO.

Dimensions

(mm)

Set screw specifications

(mm)

Load

(Kgf)

weight
dDd1BinmBeG(UNF)CrCor(Kg)

7/8

UC 305-14 M-F62.035.538.015.023.021.06.0M6x1
1/4-28		228011700.35

15/1

UC 305 -15 M-F
6UC 305 M-F
25UC 305-16 M-F

1-1/8

UC 306-18 M-F72.044.543.017.026.024.06.0M6x1
1/4-28		276015500.55
30UC 306 M-F

1-3/16

UC 306-19 M-F

1-1/4

UC 307-20 M-F80.049.048.019.029.025.08.0M8x1
5/16-24		342019600.80

1-5/16

UC 307-21 M-F

1-3/8

UC 307-22 M-F
35UC 307 M-F

1-7/16

UC 307-23 M-F

1-1/2

UC 308-24 M-F90.056.552.019.033.028.010.0M10x1.25
3/8-24		414024501.00
1-9/16UC 308-25 M-F
40UC 308 M-F

1-5/8

UC 309-26 M-F100.062.057.022.035.030.010.0M10x1.25
3/8-24		541032501.30

1-11/16

UC 309-27 M-F

1-3/4

UC 309-28 M-F
45UC 309 M-F

1-7/8

UC 310-30 M-F110.069.061.022.039.032.012.0M12x1.25
7/16-20		630038601.70
1-15/16UC 310-31 M-F
50UC 310 M-F
2UC 310-32 M-F
2UC 311-32 M-F120.075.066.025.041.034.012.0M12x1.25
7/16-20		730045701.95

2-1/8

UC 311-34 M-F
55UC 311 M-F

2-3/16

UC 311-35 M-F

2-1/4

UC 312-36 M-F130.081.071.026.045.036.012.0M12x1.25
7/16-20		833052902.60
60UC 312 M-F

2-3/8

UC 312-38 M-F

2-7/16

UC 312-39 M-F

2-1/2

UC 313-40 M-F140.087.575.030.045.038.012.0M12x1.25
7/16-20		958061703.25
65UC 313 M-F

2-3/4

UC 314 -44 M-F150.094.078.031.047.040.012.0M12x1.251064069403.95
70UC 314 M-F
2-15/16UC 315-47 M-F160.0100.582.032.050.042.014.0M14x1.5
9/16-18		1157078404.55
75UC 315 M-F
3UC 315-48 M-F
80UC 316 M-F170.0108.086.034.052.044.014.0M14x1.51254088305.55

3-1/4

UC 317-52 M-F180.0114.096.040.056.046.016.0M16x1.51353098506.95
85UC 317 M-F

3-7/16

UC 318-55 M-F190.0120.096.040.056.048.016.0M16x1.514590110207.95

3-1/2

UC 318-56 M-F
90UC 318 M-F
95UC 319 M-F200.0126.5103.041.062.050.018.0M16x1.515920124508.90

3-3/4

UC 319-60 M-F
100UC 319-100 M-F
100UC 320 M-F
3-15/16UC 320-63 M-F215.0134.5108.042.066.054.018.0M18x1.5
3/4-16		175101429011.10
4UC 320-64 M-F
110UC 322 M-F240.0151.7117.046.071.059.018.0M18x1.5209001820014.30
12UC 324 M-F260.0165.2126.051.075.063.018.0M18x1.5
3/4-16		211001880018.50
4-15/16UC 324 -79 M-F
130UC 326 M-F280.0178.3135.054.081.067.020.0M20x1.5233002180023.00
140UC 328 M-F300.0190.4145.059.086.072.020.0M20x1.5233002180028.50
