Shaft diameter | Block bearing model | Dimensions(mm) | bolt specification | Bearing Type | Block model | weight | ||||||||||||||
d | L | P | A2 | A1 | A | j | K | N | J | f | S | E | ||||||||
(min.) | (mm) | |||||||||||||||||||
1/2
5/8
11/16 | 12
15
17 | UCFC201 201-8 202 202-10 203 203-11
| 90 | 70 | 10 | 19 | 23 | 4 | 5 | 10 | 49,5 | 55 | 11,5 | 25,9 | M8 | UC201 201-8 202 202-10 203 203-11 | FC203 | 0,56 | ||
3/4 |
20 | UCFC204-12 204
| 100 | 78 | 10 | 20,5 | 25,5 | 5 | 6 | 12 | 55,1 | 62 | 12,7 | 28,3 | M10 | UC204-12 204 | FC204 | 0,79 | ||
7/8 15/16
1 |
25 | UCFC205-14 205-15 205 205-16
| 115 | 90 | 10 | 21 | 27 | 6 | 7 | 12 | 63,6 | 70 | 14,3 | 29,7 | M10 | UC205-14 205-15 205 205-16 | FC205 | 0,96 | ||
1-1/8
1-3/16 1-1/4 |
30 | UCFC206-18 206 206-19 206-20 | 125 | 100 | 10 | 23 | 31 | 8 | 8 | 12 | 70,7 | 80 | 15,9 | 32,2 | M10 | UC206-18 206 206-19 206-20 | FC206 | 1,37 | ||
1-1/4 1-5/16 1-3/8
1-7/16 |
35 | UCFC207-20 207-21 207-22 207 207-23 | 135 | 110 | 11 | 26 | 34 | 8 | 9 | 14 | 77,8 | 90 | 17,5 | 36,4 | M12 | UC207-20 207-21 207-22 207 207-23 | FC207 | 1,70 | ||
1-1/2 1-9/16 |
40 | UCFC208-24 208-25 208 | 145 | 120 | 11 | 26 | 36 | 10 | 9 | 14 | 84,8 | 100 | 19 | 41,2 | M12 | UC208-24 208-25 208 | FC208 | 2,0 | ||
1-5/8 1-11/16 1-3/4 |
45 | UCFC209-26 209-27 209-28 209 | 160 | 132 | 10 | 26 | 38 | 12 | 10 | 16 | 93,3 | 105 | 19 | 40,2 | M14 | UC209-26 209-27 209-28 209 | FC209 | 2,7 | ||
1-7/8 1-15/16 |
50 | UCFC210-30 210-31 210 | 165 | 138 | 10 | 28 | 40 | 12 | 14 | 16 | 97,6 | 110 | 19 | 42,6 | M14 | UC210-30 210-31 210 | FC210 | 2,9 | ||
2 2-1/8
2-3/16 |
55 | UCFC211-32 211-34 211 211-35 | 185 | 150 | 13 | 30 | 42 | 12 | 13 | 19 | 106,1 | 125 | 22,2 | 46,4 | M16 | UC211-32 211-34 211 211-35 | FC211 | 4,2 | ||
2-1/4
2-3/8 2-7/16 |
60 | UCFC212-36 212 212-38 212-39 | 195 | 160 | 17 | 36 | 48 | 12 | 15 | 19 | 113,1 | 135 | 25,4 | 56,7 | M16 | UC212-36 212 212-38 212-39 | FC212 | 4,94 | ||
2-1/2 |
65 | UCFC213-40 213 | 205 | 170 | 16 | 35 | 49 | 14 | 15 | 19 | 120,2 | 145 | 25,4 | 55,7 | M16 | UC213-40 213 | FC213 | 5,7 | ||
2-3/4 |
70 | UCFC214-44 214 | 215 | 177 | 17 | 38 | 52 | 14 | 16 | 19 | 125,1 | 150 | 30,2 | 61,4 | M16 | UC214-44 214 | FC214 | 6,8 | ||
3 | 75 | UCFC215 215-48 | 220 | 184 | 18 | 39 | 55 | 16 | 17 | 19 | 130,1 | 160 | 33,3 | 62,5 | M16 | UC215 215-48 | FC215 | 7,2 | ||
80 | UCFC216 | 240 | 200 | 18 | 42 | 58 | 16 | 18 | 23 | 141,4 | 170 | 33,3 | 67,3 | M20 | UC216 | FC216 | 8,7 | |||
3-1/4 |
85 | UCFC217-52 217 | 250 | 208 | 18 | 45 | 63 | 18 | 20 | 23 | 141,1 | 180 | 34,1 | 69,6 | M20 | UC217-52 217 | FC217 | 10,3 | ||
3-1/2 |
90 | UCFC218-56 218 | 265 | 220 | 22 | 50 | 68 | 18 | 20 | 23 | 155,5 | 190 | 39,7 | 78,3 | M20 | UC218-56 218 | FC218 | 13,5 |
