Shaft diameter | Block bearing model | Dimensions(mm) | bolt specification | Bearing Type | Block model | weight (KG) | |||||||||
d | H | J | L | A2 | A1 | A | E | N | S | ||||||
(min.) | (mm) | ||||||||||||||
1/2
5/8
11/16 | 12
15
17 | SAFL201 201-8 202 202-10 203 203-11 | 99 | 76,5 | 57 | 15 | 11 | 24,5 | 37,1 | 11,5 | 6,5 | M10 | SA201 201-8 202 202-10 203 203-11 | FL203 | 0,38 |
3/4 |
20 | SAFL204-12 204 | 113 | 90 | 60 | 15 | 11 | 25,5 | 38,4 | 11,5 | 7,5 | M10 | SA204-12 204 | FL204 | 0,39
|
7/8 15/16
1 |
25 | SAFL205-14 205-15 205 205-16 | 130 | 99 | 68 | 16 | 13 | 27 | 39,4 | 11,5 | 7,5 | M10 | SA205-14 205-15 205 205-16 | FL205 | 0,58
|
1- 1/8
1-3/16 1- 1/4 |
30 | SAFL206-18 206 206-19 206-20 | 148 | 117 | 80 | 18 | 13 | 31 | 44,7 | 11,5 | 9 | M10 | SA206-18 206 206-19 206-20 | FL206 | 0,84
|
1-1/4 1-5/16 1-3/8
1-7/16 |
35 | SAFL207-20 207-21 207-22 207 207-23 | 161 | 130 | 90 | 19 | 14 | 34 | 48,4 | 14 | 9,5 | M12 | SA207-20 207-21 207-22 207 207-23 | FL207 | 1,36
|
1-1/2 1-9/16 |
40 | SAFL208-24 208-25 208 | 175 | 144 | 100 | 21 | 14 | 36 | 53,7 | 14 | 11 | M12 | SA208-24 208-25 208 | FL208 | 1,38 |
1-5/8 1-11/16 1-3/4 |
45 | SAFL209-26 209-27 209-28 209 | 188 | 148 | 108 | 22 | 16 | 38 | 54,7 | 18 | 11 | M16 | SA209-26 209-27 209-28 209 | FL209 | 1,86 |
1-7/8 1-15/16
2 |
50 | SAFL210-30 210-31 210 210-32 | 197 | 157 | 115 | 22 | 16 | 40 | 54,7 | 18 | 11 | M16 | SA210-30 210-31 210 210-32 | FL210 |
2,17 |
2 2-1/8
2-3/16 |
55 | SAFL211-32 211-34 211 211-35 | 224 | 184 | 130 | 25 | 18 | 43 | 61,4 | 18 | 12 | M16 | SA211-32 211-34 211 211-35 | FL211 | 2,81
|
2-1/4
2-3/8 2-7/16 |
60 | SAFL212-36 212 212-38 212-39 | 250 | 202 | 140 | 29 | 18 | 48 | 66,3 | 18 | 12 | M16 | SA212-36 212 212-38 212-39 | FL212 | 3,66 |
Shaft diameter | Block bearing model | Dimensions(mm) | bolt specification | Bearing Type | Block model | weight (KG) | |||||||||
d | H | J | L | A2 | A1 | A | E | N | S | ||||||
(min.) | (mm) | ||||||||||||||
1/2
5/8
11/16 | 12
15
17 | SAFL201 201-8 202 202-10 203 203-11 | 99 | 76,5 | 57 | 15 | 11 | 24,5 | 37,1 | 11,5 | 6,5 | M10 | SA201 201-8 202 202-10 203 203-11 | FL203 | 0,38 |
3/4 |
20 | SAFL204-12 204 | 113 | 90 | 60 | 15 | 11 | 25,5 | 38,4 | 11,5 | 7,5 | M10 | SA204-12 204 | FL204 | 0,39
|
7/8 15/16
1 |
25 | SAFL205-14 205-15 205 205-16 | 130 | 99 | 68 | 16 | 13 | 27 | 39,4 | 11,5 | 7,5 | M10 | SA205-14 205-15 205 205-16 | FL205 | 0,58
|
1- 1/8
1-3/16 1- 1/4 |
30 | SAFL206-18 206 206-19 206-20 | 148 | 117 | 80 | 18 | 13 | 31 | 44,7 | 11,5 | 9 | M10 | SA206-18 206 206-19 206-20 | FL206 | 0,84
|
1-1/4 1-5/16 1-3/8
1-7/16 |
35 | SAFL207-20 207-21 207-22 207 207-23 | 161 | 130 | 90 | 19 | 14 | 34 | 48,4 | 14 | 9,5 | M12 | SA207-20 207-21 207-22 207 207-23 | FL207 | 1,36
|
1-1/2 1-9/16 |
40 | SAFL208-24 208-25 208 | 175 | 144 | 100 | 21 | 14 | 36 | 53,7 | 14 | 11 | M12 | SA208-24 208-25 208 | FL208 | 1,38 |
1-5/8 1-11/16 1-3/4 |
45 | SAFL209-26 209-27 209-28 209 | 188 | 148 | 108 | 22 | 16 | 38 | 54,7 | 18 | 11 | M16 | SA209-26 209-27 209-28 209 | FL209 | 1,86 |
1-7/8 1-15/16
2 |
50 | SAFL210-30 210-31 210 210-32 | 197 | 157 | 115 | 22 | 16 | 40 | 54,7 | 18 | 11 | M16 | SA210-30 210-31 210 210-32 | FL210 |
2,17 |
2 2-1/8
2-3/16 |
55 | SAFL211-32 211-34 211 211-35 | 224 | 184 | 130 | 25 | 18 | 43 | 61,4 | 18 | 12 | M16 | SA211-32 211-34 211 211-35 | FL211 | 2,81
|
2-1/4
2-3/8 2-7/16 |
60 | SAFL212-36 212 212-38 212-39 | 250 | 202 | 140 | 29 | 18 | 48 | 66,3 | 18 | 12 | M16 | SA212-36 212 212-38 212-39 | FL212 | 3,66 |
