Shaft diameter | Block bearing model | Dimensions(mm) | Bolt specifications | Bearing Type | Block model | weight (kg) | ||||||||||||
d | L | P | A2 | A1 | A | J | K | N | J | f | S | E | ||||||
(min.) | (mm) | |||||||||||||||||
1/2
5/8
11/16 3/4 | 12
15
17
20 | NAFC201 201-8 202 202-10 203 203-11 204-12 204 | 100 | 78 | 10 | 20,5 | 25,5 | 5 | 6 | 12 | 55,1 | 62 | 17 | 36,3 | M10 | NA201 201-8 202 202-10 203 203-11 204-12 204 | FC204 | 0,83 |
7/8 15/16
1 |
25 | NAFC205-14 205-15 205 205-16 | 115 | 90 | 10 | 21 | 27 | 6 | 7 | 12 | 63,6 | 70 | 17,4 | 36,9 | M10 | NA205-14 205-15 205 205-16 | FC205 | 1,1 |
1-1/8
1-3/16 1-1/4 |
30 | NAFC206-18 206 206-19 206-20 | 125 | 100 | 10 | 23 | 31 | 8 | 8 | 12 | 70,7 | 80 | 18,2 | 40,1 | M10 | NA206-18 206 206-19 206-20 | FC206 | 1,5 |
1-1/4 1-5/16 1-3/8
1-7/16 |
35 | NAFC207-20 207-21 207-22 207 207-23 | 135 | 110 | 11 | 26 | 34 | 8 | 9 | 14 | 77,8 | 90 | 18,8 | 43,3 | M12 | NA207-20 207-21 207-22 207 207-23 | FC207 | 1,8 |
1-1/2 1-9/16 |
40 | NAFC208-24 208-25 208 | 145 | 120 | 11 | 26 | 36 | 10 | 9 | 14 | 84,8 | 100 | 21,4 | 45,9 | M12 | NA208-24 208-25 208 | FC208 | 2,2 |
1-5/8 1-11/16 1-3/4 |
45 | NAFC209-26 209-27 209-28 209 | 160 | 132 | 10 | 26 | 38 | 12 | 10 | 16 | 93,3 | 105 | 21,4 | 44,9 | M14 | NA209-26 209-27 209-28 209 | FC209 | 2,8 |
1-7/8 1-15/16 |
50 | NAFC210-30 210-31 210 | 165 | 138 | 10 | 28 | 40 | 12 | 14 | 16 | 97,6 | 110 | 24,6 | 48,1 | M14 | NA210-30 210-31 210 | FC210 | 3,3 |
2 2-1/8 2-3/16 |
55 | NAFC211-32 211-34 211 211-35 | 185 | 150 | 13 | 30 | 42 | 12 | 13 | 19 | 106,1 | 125 | 27,7 | 56,6 | M16 | NA211-32 211-34 211 211-35 | FC2U | 4,5 |
2-1/4
2-3/8 2-7/16 |
60 | NAFC212-36 212 212-38 212-39 | 195 | 160 | 17 | 36 | 48 | 12 | 15 | 19 | 113,1 | 135 | 30,9 | 63,8 | M16 | NA212-36 212 212-38 212-39 | FC212 | 5,7 |
2-1/2 |
65 | NAFC213-40 213 | 205 | 170 | 16 | 35 | 49 | 14 | 15 | 19 | 120,2 | 145 | 34,1 | 67,6 | M16 | NA213-40 213 | FC213 | 6,5 |
2-3/4 |
70 | NAFC214-44 214 | 215 | 177 | 17 | 38 | 52 | 14 | 16 | 19 | 125,1 | 150 | 34,1 | 68,6 | M16 | NA214-44 214 | FC214 | 7,2 |
3 | 75 | NAFC215 215-48 | 220 | 184 | 18 | 39 | 55 | 16 | 17 | 19 | 130,1 | 160 | 37,3 | 72,8 | M16 | NA215 215-48 | FC215 | 8 |
80 | NAFC216 | 240 | 200 | 18 | 42 | 58 | 16 | 18 | 23 | 141,4 | 170 | 37,3 | 75,9 | M20 | NA216 | FC216 | 9,53 | |
3-1/4 |
85 | NAFC217-52 217 | 250 | 208 | 18 | 45 | 63 | 18 | 20 | 23 | 147,1 | 180 | 23,4 | 67,8 | M20 | NA217-52 217 | FC217 | |
3-1/2 |
90 | NAFC218-56 218 | 265 | 220 | 22 | 50 | 68 | 18 | 20 | 23 | 155,5 | 190 | 24,5 | 70 | M20 | NA218-56 218 | FC218 |
