J | Pitch circle diameter | 122 | mm |
D | Outside diameter | 140 | mm |
H/T | Hole/Thread | 6xM12 | mm |
d | Bore diameter | 44 | mm |
C | D-shape hole cut out dimension | 40 | mm |
G | Internal Thread | 26 | mm |
L | Total length | 85 | mm |
L1 | Total flange length | 71 | mm |
E | Length of D shape | 14 | mm |
F | Length of threaded part | 26 | mm |
kg | Mass | 4.802 | kg |
Cdyn | Dynamic load rating | 94.45 | kN |
Co | Static load rating | 77.88 | kN |
Pu | Fatigue load limit | 3.271 | kN |
J | Pitch circle diameter | 122 | mm |
D | Outside diameter | 140 | mm |
H/T | Hole/Thread | 6xM12 | mm |
d | Bore diameter | 44 | mm |
C | D-shape hole cut out dimension | 40 | mm |
G | Internal Thread | 26 | mm |
L | Total length | 85 | mm |
L1 | Total flange length | 71 | mm |
E | Length of D shape | 14 | mm |
F | Length of threaded part | 26 | mm |
kg | Mass | 4.802 | kg |
Cdyn | Dynamic load rating | 94.45 | kN |
Co | Static load rating | 77.88 | kN |
Pu | Fatigue load limit | 3.271 | kN |
