J | Pitch circle diameter | 108 | mm |
D | Outside diameter | 145 | mm |
M | Outher Thread | M24x2 | mm |
L | Total length | 108 | mm |
L1 | Stud thread length | 32.5 | mm |
L2 | The distance from the mounting surface to the front of the flange on which the disc is installed | 20.5 | mm |
D3 | The outer diameter of the hub body | 79 | mm |
F | Length of threaded part | 24 | mm |
kg | Mass | 3.985 | kg |
Cdyn | Dynamic load rating | 60 | kN |
Co | Static load rating | 45.8 | kN |
Pu | Fatigue load limit | 1.924 | kN |
J | Pitch circle diameter | 108 | mm |
D | Outside diameter | 145 | mm |
M | Outher Thread | M24x2 | mm |
L | Total length | 108 | mm |
L1 | Stud thread length | 32.5 | mm |
L2 | The distance from the mounting surface to the front of the flange on which the disc is installed | 20.5 | mm |
D3 | The outer diameter of the hub body | 79 | mm |
F | Length of threaded part | 24 | mm |
kg | Mass | 3.985 | kg |
Cdyn | Dynamic load rating | 60 | kN |
Co | Static load rating | 45.8 | kN |
Pu | Fatigue load limit | 1.924 | kN |
