J | Pitch circle diameter | 98 | mm |
D | Outside diameter | 117 | mm |
H/T | Hole/Thread | 4xM12x1.25 | mm |
d1 | Bore diameter | 30 | mm |
L1 | Total flange length | 60 | mm |
kg | Mass | 1.96 | kg |
Cdyn | Dynamic load rating | 60 | kN |
Co | Static load rating | 45.8 | kN |
Pu | Fatigue load limit | 1.92 | kN |
J | Pitch circle diameter | 98 | mm |
D | Outside diameter | 117 | mm |
H/T | Hole/Thread | 4xM12x1.25 | mm |
d1 | Bore diameter | 30 | mm |
L1 | Total flange length | 60 | mm |
kg | Mass | 1.96 | kg |
Cdyn | Dynamic load rating | 60 | kN |
Co | Static load rating | 45.8 | kN |
Pu | Fatigue load limit | 1.92 | kN |
