J | Pitch circle diameter | 80 | mm |
D | Outside diameter | 100 | mm |
H/T | Hole/Thread | 6xM8 | mm |
d | Bore diameter | 20 | mm |
C | D-shape hole cut out dimension | 18.5 | mm |
M | Outher Thread | M16 | mm |
L | Total length | 73 | mm |
L1 | Total flange length | 38 | mm |
E | Length of D shape | 11 | mm |
F | Length of threaded part | 24 | mm |
kg | Mass | 0.99 | kg |
Cdyn | Dynamic load rating | 32 | kN |
Co | Static load rating | 22 | kN |
Pu | Fatigue load limit | 0.92 | kN |
J | Pitch circle diameter | 80 | mm |
D | Outside diameter | 100 | mm |
H/T | Hole/Thread | 6xM8 | mm |
d | Bore diameter | 20 | mm |
C | D-shape hole cut out dimension | 18.5 | mm |
M | Outher Thread | M16 | mm |
L | Total length | 73 | mm |
L1 | Total flange length | 38 | mm |
E | Length of D shape | 11 | mm |
F | Length of threaded part | 24 | mm |
kg | Mass | 0.99 | kg |
Cdyn | Dynamic load rating | 32 | kN |
Co | Static load rating | 22 | kN |
Pu | Fatigue load limit | 0.92 | kN |
